List of on-the-fly CDN operations

Uploadcare CDN features on-the-fly image optimization, a large set of image transformations, and non-image file operations, such as getting file information or changing file delivery behavior.

https://ucarecdn.com/85b5644f-e692-4855-9db0-8c5a83096e25/
https://ucarecdn.com/:uuid/

You can find detailed specifications of all CDN operations in the URL API.

Image processing operations

Key types of image operations are:

When applying any image operation, a new file is created (cached on our CDN, and not counted towards your storage limits). If not set, this file is encoded with the default quality and original format. However, you can adjust them to meet your requirements better.

Limitations

Image processing operations have limits that you should consider.

Input image formats

List of supported image formats:

  • AVIF
  • BMP
  • GIF
  • HEIC
  • JPEG
  • PCX
  • PNG
  • TGA
  • TIFF
  • WEBP

Some formats have several variations, and we support the most popular ones. Contact sales if you require additional formats or variations.

Without any image processing operation in the URL, CDN instructs browsers to show images (Content-Disposition: inline) and download other file types (Content-Disposition: attachment). Browsers may not show all image formats, such as TIFF and HEIC formats. If you need to display an image, add any image processing operation, -/preview/ for instance.

Core operations

When processing images, you must add at least one of the following operations via their respective URL directives:

File size

Image processing operations can be applied to files smaller than 100 MB.

The file size limit can be increased individually. To do this, contact our sales team.

Output image dimensions

The dimensions you specify for the last operation should not exceed 3000x3000 pixels. You can go up to 5000x5000 pixels by explicitly setting your image format to JPEG, /format/jpeg/.

You can extend the output max resolution up to 8192x8192, and up to 16384x16384 for JPEGs in trade-off for increased latency. Contact our sales team to learn more about this option.

SVG files

Any image transformation CDN URL is valid with an SVG file. Most operations don’t affect the response SVG body, while geometric operations (crop, preview, resize, scale_crop) change SVG attributes and work as expected. To apply full range of operations on SVG file, it should be rasterized by applying /rasterize/ operation. Read more about SVGs.

SVGs uploaded before May 26, 2021 still have is_image: false and adding processing operations to them will result in error. Contact support to batch process previously uploaded files.

Image resolution

We don’t provide on-the-fly image processing for images greater than 75 MP in resolution: those are tagged as non-image files and can only be delivered via CDN as-is. Adding processing operations to non-image files will result in an error.

Simple rotation

When the only image transformation you want is rotating, consider using the preview control without any arguments. When you use any of the transformations, we automatically rotate images according to their EXIF orientation.

Animated images

Animated images are treated as static by the transformations engine. Learn more about animated images optimization.

Show or download

-/inline/yes/ -/inline/no/

By default, CDN instructs browsers to show images and download other file types. The inline control allows you to change this behavior.

Change filename

Your original filenames can be accessed via REST API. Request to receive a JSON response with file parameters including original_filename.

You can set an optional filename that users will see instead of the original name:

1https://ucarecdn.com/:uuid/:filename

:filename should comply with file name conventions and it should be a valid part of a URL. For example, filename.ext.

Get file information as JSON

-/json/

Returns file-related information, such as image dimensions or geotagging data in the JSON format. This operation should be the last in the URL.

1$ curl "https://ucarecdn.com/6374b0f2-f9f9-4dcc-b709-22507e1976b8/-/json/"
2{
3    "id": "6374b0f2-f9f9-4dcc-b709-22507e1976b8",
4    "format": "JPEG",
5    "color_mode": "RGB",
6    "width": 3024,
7    "height": 4032,
8    "sequence": false,
9    "orientation": 1,
10    "dpi": [72, 72],
11    "geo_location": {"latitude": 59.9814, "longitude": 30.2118},
12    "datetime_original": "2019-06-23T14:22:13",
13    "hash": "a51a7375cc893599"
14}

This operation can also be applied to any transformed version of an image. The response will contain the original key with information about the original image.

1$ curl "https://ucarecdn.com/6374b0f2-f9f9-4dcc-b709-22507e1976b8/-/preview/320x320/-/json/"
2{
3    "id": "/6374b0f2-f9f9-4dcc-b709-22507e1976b8/-/preview/320x320/",
4    "original": {
5        "id": "6374b0f2-f9f9-4dcc-b709-22507e1976b8",
6        "format": "JPEG",
7        "color_mode": "RGB",
8        "width": 3024,
9        "height": 4032,
10        "sequence": false,
11        "orientation": 1,
12        "dpi": [72, 72],
13        "geo_location": {"latitude": 59.9814, "longitude": 30.2118},
14        "datetime_original": "2019-06-23T14:22:13"
15    },
16    "width": 240,
17    "height": 320,
18    "hash": "a51a7375cc893599",
19    "blurhash": "mSG8J.VsFzEN0fI;nj$*E5s;xBbEM|t7t6of-Qt7NLNHxZR*NHae"
20}

While most fields are self-explanatory, additional information about the hash and blurhash fields can be found below.

Perceptual hash

The file info response includes a hash field with the perceptual hash value calculated using the pixel contents of an image. Perceptual hashing is a common fingerprinting technique used to quickly compare images and find duplicates or similar images. Uploadcare automatically calculates a 64-bit perceptual hash value and returns it as a HEX string. This makes it easy to identify image duplicates by directly comparing their perceptual hash values. To find similar images, it’s important to compare perceptual hash values bitwise using the Hamming distance. A small number of unmatched bits (e.g., up to 8 bits) indicates subtle differences in visual content, while non-similar images will typically have more than 8 differing bits.

Blurhash

The file info response includes a blurhash field containing a compact string representation of the image. This representation allows for reconstructing an image that captures the general structure and color scheme without fine details, making it useful as a blurred placeholder while the full image loads. This enhances the user experience on platforms with varying image loading times.

For the best user experience, make sure to store and deliver blurhash values along with your HTML markup or JSON data from the server, instead of making requests to the API on each page load.

Find more info on the official Blurhash site.


Original image
Seperate request, about 11Kb

blurhash representation

Blurhash representation
Restored from 52 bytes string

File groups operations

File groups serve as collections of files that help you organize content within your Uploadcare project. A group itself and files within it MUST belong to the same project.

Most often, file groups are used in the following cases:

Learn more about file groups.
