Videoframe

Videoframe returns a single still image taken from a video at the timestamp you specify. It works on the fly, like other CDN operations: there is no processing job to start, nothing to poll, and no new file added to your project.

The workflow is the same as with other CDN operations. The only difference is the videoframe URL directive should be included after the / separator, not /-/, and it takes the timestamp as a path segment:

https://:subdomain.ucarecd.net/:uuid/videoframe/:timestamp/

:subdomain is your project’s subdomain — find it in Delivery.

This feature works for video files only. A file counts as a video when its file information has the content_info.video key (see the file info example). For any other file you’ll get an HTTP 400 error.

Timestamp

/videoframe/:timestamp/

Sets the position in the video the frame is taken from. Two forms are supported.

• Clock form — HH:MM:SS with optional fractional seconds, HH:MM:SS.mmm.
  Hours range from 00 to 99, minutes and seconds from 00 to 59. All parts are zero-padded to two digits.
  Examples: 00:00:05, 00:01:23.500, 01:00:00.
• Seconds form — a number of seconds followed by s.
  Takes a non-negative integer or a decimal value.
  Examples: 30s, 30.5s.

A timestamp that doesn’t match either form returns an HTTP 400 error. Notably, the clock form has to be fully padded and can’t be shortened: 0:00:05, 00:05, and 00:60:00 are all invalid.

The timestamp also has to fall within the video. You can read the video length from the content_info.video.duration field of the file information object — it’s given in milliseconds.

Output

The extracted frame is always a PNG image at the video’s native resolution. There is no size argument — use image operations to scale or convert it.

The frame is served with Content-Type: image/png and shown in the browser rather than downloaded:

content-type: image/png
content-disposition: inline; filename=frame-00-00-02.png

The default filename is built from the timestamp, with : replaced by -. You can set your own filename the same way as for any other file, by adding it after the trailing slash:

https://:subdomain.ucarecd.net/:uuid/videoframe/00:00:02/poster.png

Transform the extracted frame

The frame goes through the regular image pipeline, so you can append any image operations after it — resize, crop, format conversion, quality, effects, overlays, and the JSON request:

This is how you get a poster image in the format and size you need, in one request:

<video poster="https://examples.ucarecd.net/e879b607-e881-4f2e-8788-9c3297f28db6/videoframe/00:00:01/-/resize/1280x/-/format/jpeg/poster.jpg" controls>
  <source src="https://examples.ucarecd.net/e879b607-e881-4f2e-8788-9c3297f28db6/" type="video/mp4"/>
</video>

The -/json/ operation describes the extracted frame, not the source video:

{
  "id": "e879b607-e881-4f2e-8788-9c3297f28db6",
  "format": "PNG",
  "width": 1920,
  "height": 1080,
  "sequence": false,
  "hash": "cbc9c9cbc0373634"
}

Operation permissions and project-level transformation settings apply the same way as for image URLs.

Caching

The extracted frame is cached per timestamp: the first request for a given timestamp extracts the frame and takes longer, while all following requests for the same timestamp are served from the cache. Different timestamps are extracted and cached independently.

Any image operations you append are applied on top of that cached frame, so switching from -/resize/300x/ to -/resize/600x/ doesn’t re-extract anything. Every complete URL gets its own CDN cache entry and is served as an immutable response.

Videoframe vs. video thumbnails

Video processing can also produce thumbnails with the thumbs operation. The two features solve different problems:

Errors
